使用MAX31875和STM32F405RG体验温度测量的未来

/*!
 * \file
 * \brief Thermo6 Click example
 *
 * # Description
 * Demo application shows ambient temperature reading using Thermo 6 Click.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Configuring Clicks and log objects.
 * Setting the Click in the default configuration to start the measurement.
 *
 * ## Application Task
 *  It measures the temperature and logs a message about the current temperature.
 *
 * \author Katarina Perendic
 *
 */
// ------------------------------------------------------------------- INCLUDES

#include "board.h"
#include "log.h"
#include "thermo6.h"

// ------------------------------------------------------------------ VARIABLES

static thermo6_t thermo6;
static log_t logger;

// ------------------------------------------------------ APPLICATION FUNCTIONS

void application_init ( void )
{
    log_cfg_t log_cfg;
    thermo6_cfg_t cfg;

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, "---- Application Init ----" );

    //  Click initialization.

    thermo6_cfg_setup( &cfg );
    THERMO6_MAP_MIKROBUS( cfg, MIKROBUS_1 );
    thermo6_init( &thermo6, &cfg );

    thermo6_default_cfg( &thermo6 );
    log_info( &logger, "---- Start measurement ----");
    Delay_ms ( 1000 );
}

void application_task ( void )
{
    float temperature;

    //  Task implementation.

    temperature = thermo6_get_temperature_data( &thermo6, THERMO6_TEMP_FORMAT_CELSIUS );
    log_printf( &logger, ">> Temperature is %.3f C \r\n", temperature );

    Delay_ms ( 1000 );
}

int main ( void )
{
    /* Do not remove this line or clock might not be set correctly. */
    #ifdef PREINIT_SUPPORTED
    preinit();
    #endif

    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}


// ------------------------------------------------------------------------ END
