使用DS2401和ATmega644创建安全且独特的数字身份

/*!
 * @file main.c
 * @brief UNIQUE ID Click example.
 *
 * # Description
 * This example demonstrates the use of UNIQUE ID click board by reading and
 * displaying Family Code and Serial Number on the UART Terminal.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initializes both logger config object and
 * click config object.
 *
 * ## Application Task
 * Demonstrates the usage of uniqueid_read_id function,
 * which stores the Family Code and Serial Number of the click in
 * family_code and serial_num variables. Both values will be displayed
 * on the UART Terminal.
 *
 * @author Aleksandra Cvjeticanin
 *
 */

#include "board.h"
#include "log.h"
#include "uniqueid.h"

static uniqueid_t uniqueid;
static log_t logger;


void application_init ( void )
{
    log_cfg_t log_cfg;  /**< Logger config object. */
    uniqueid_cfg_t uniqueid_cfg;  /**< Click config object. */

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, " Application Init " );

    // Click initialization
    uniqueid_cfg_setup( &uniqueid_cfg );
    UNIQUEID_MAP_MIKROBUS( uniqueid_cfg, MIKROBUS_1 );
    if ( ONE_WIRE_ERROR == uniqueid_init( &uniqueid, &uniqueid_cfg ) )
    {
        log_error( &logger, " Initialization error." );
        for ( ; ; );
    }

    log_info( &logger, " Application Task " );
}

void application_task ( void )
{
    uint8_t family_code;
    uint8_t serial_num[ 6 ];

    if ( UNIQUEID_OK == uniqueid_read_id( &uniqueid, &family_code, &serial_num[ 0 ] ) )
    {
        log_printf( &logger, "Family Code = 0x%.2X\r\n", ( uint16_t ) family_code );
        log_printf( &logger, "Serial Number = 0x%.2X%.2X%.2X%.2X%.2X%.2X\r\n",
                    ( uint16_t ) serial_num[ 0 ], ( uint16_t ) serial_num[ 1 ],
                    ( uint16_t ) serial_num[ 2 ], ( uint16_t ) serial_num[ 3 ],
                    ( uint16_t ) serial_num[ 4 ], ( uint16_t ) serial_num[ 5 ] );
    }

    Delay_ms( 1000 );
}

void main ( void )
{
    application_init( );

    for ( ; ; )
    {
        application_task( );
    }
}

// ------------------------------------------------------------------------ END
