使用LTC3586和PIC18LF25K50创建高效电源管理器

/*!
 * \file
 * \brief BATT-MAN Click example
 *
 * # Description
 * BATT-MAN Click is a very versatile battery operated power manager. When powered via mikroBUS,
 * it will charge the connected Li-Ion/Li-Po 3.7V battery, while providing the output voltage
 * on all its outputs at the same time.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initializes the Click driver and logger utility and enables the Click board.
 *
 * ## Application Task
 * Checks the charging indicator status, and in relation to its state
 * it displays an appropriate message on USB UART.
 *
 * \author MikroE Team
 *
 */
// ------------------------------------------------------------------- INCLUDES

#include "board.h"
#include "log.h"
#include "battman.h"

// ------------------------------------------------------------------ VARIABLES

static battman_t battman;
static log_t logger;
static uint8_t chg_flag;

// ------------------------------------------------------ APPLICATION FUNCTIONS

void application_init ( void )
{
    log_cfg_t log_cfg;
    battman_cfg_t cfg;

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, "---- Application Init ----" );

    //  Click initialization.

    battman_cfg_setup( &cfg );
    BATTMAN_MAP_MIKROBUS( cfg, MIKROBUS_1 );
    battman_init( &battman, &cfg );

    battman_set_enable( &battman, 1 );
    log_printf( &logger, "BATT-MAN Click enabled.\r\n" );
    chg_flag = 0;
}

void application_task ( void )
{
    if ( !battman_get_charging_indicator ( &battman ) )
    {
        if ( chg_flag == 1 )
        {
            log_printf( &logger, "Charging enabled.\r\n" );
        }
        chg_flag = 0;
    }
    else
    {
        if ( chg_flag == 0 )
        {
            log_printf( &logger, "Charging disabled.\r\n" );
        }
        chg_flag = 1;
    }
}

int main ( void )
{
    /* Do not remove this line or clock might not be set correctly. */
    #ifdef PREINIT_SUPPORTED
    preinit();
    #endif

    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}


// ------------------------------------------------------------------------ END
