使用BME280和PIC18F26K40精确监测和控制室内气候条件

/*!
 * @file
 * @brief Weather Click example
 *
 * # Description
 * This demo-app shows the temperature, pressure and humidity measurement using Weather Click.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Configuring Clicks and log objects.
 * Setting the Click in the default configuration to start the measurement.
 *
 * ## Application Task
 * Reads Temperature data, Relative Humidity data and Pressure data,
 * and displays them on USB UART every 1500ms.
 *
 * @author MikroE Team
 *
 */

#include "board.h"
#include "log.h"
#include "weather.h"

static weather_t weather;
static log_t logger;

void application_init ( void )
{
    log_cfg_t log_cfg;
    weather_cfg_t weather_cfg;

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, " Application Init " );

    // Click initialization.
    weather_cfg_setup( &weather_cfg );
    WEATHER_MAP_MIKROBUS( weather_cfg, MIKROBUS_1 );
    if ( WEATHER_OK != weather_init( &weather, &weather_cfg ) )
    {
        log_error( &logger, " Communication init." );
        for ( ; ; );
    }

    if ( WEATHER_OK != weather_default_cfg ( &weather ) )
    {
        log_error( &logger, " Default configuration." );
        for ( ; ; );
    }

    log_info( &logger, " Application Task " );
}

void application_task ( void )
{
    weather_data_t weather_data;

    if ( WEATHER_OK == weather_get_ambient_data( &weather, &weather_data ) )
    {
        log_printf( &logger, " \r\n ---- Weather data ----- \r\n" );
        log_printf( &logger, "[PRESSURE]: %.2f mBar.\n\r", weather_data.pressure );
        log_printf( &logger, "[TEMPERATURE]: %.2f C.\n\r", weather_data.temperature );
        log_printf( &logger, "[HUMIDITY]: %.2f %%.\n\r", weather_data.humidity );

        Delay_ms ( 1000 );
        Delay_ms ( 500 );
    }
}

int main ( void )
{
    /* Do not remove this line or clock might not be set correctly. */
    #ifdef PREINIT_SUPPORTED
    preinit();
    #endif

    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}


// ------------------------------------------------------------------------ END
