Intermediate
20 min

Develop a fully functional Wireless Mesh Network node with NC1000C-9 and PIC18F47J53

Ultra low power Ad-Hoc Wireless Mesh Networking intended for 915MHz frequency band

NeoMesh Click - 915MHz with PIC clicker

Published Jan 09, 2024

Click board™

NeoMesh Click - 915MHz

Dev.Board

PIC clicker

Compiler

NECTO Studio

MCU

PIC18F47J53

Enhance applications with this Wireless Mesh Network module solution, which is pre-certified for seamless integration and customizable for IoT and wireless networking efficiency

A

A

Hardware Overview

How does it work?

NeoMesh Click - 915MHz is based on the NC1000C-9, a wireless Mesh network module from NeoCortec. Besides being controlled by the host MCU, NeoMesh Click can be used as a standalone device. You can configure the module over the System API (SAPI), a UART-based interface with hardware flow control. This interface is configured to ensure direct compatibility with the FTDI serial to USB cable. When using the NeoMesh Click as a standalone board, the application interface of the NeoMesh module can be easily accessed through the pin header located at the side of the module. There are eight pins, six in the header labeled P2-7, which allows you to use up to 6 channels of 12-bit ADC, GPIOs, I2C sensors, and UART application APIs. Specific pins of this header can be used to interface with an external microcontroller through UART. The module also can be configured wirelessly. At the bottom side, there is an unconnected WES jumper. You can use the Wireless Encrypted Setup by connecting it, but only if it is already configured through the WES

procedure. Every WES channel has a specified AES 128 encryption key. Just beside is another jumper, VCC, this one connected. The NeoMesh is optimized for ultra-low power operation and allows operation on small batteries for several years. If you want to make an ultra-low power node, consider using the NeoMesh Click with some low-power development board with battery management, such as the Clicker 2 series or similar. This scenario is ideal where the node can send data infrequently, and the payload size is small. NeoMesh is a wireless system designed with versatility in mind, allowing users to build products in many different application areas. This system can handle data transmission, lost neighbor nodes, moving nodes, and more. Data transmission through the network is done sequentially from node to node until the data reaches its destination. There are three types of NeoMesh devices: coordinator, router, and end device. You can configure your device according to your needs. NeoMesh uses a standard UART serial interface to communicate

with the host MCU, with commonly used UART RX and TX pins and a transfer speed of 115200bps. Hardware control flow is available through the CTS pin. You can also use an I2C interface as a virtual UART. There are unpopulated pull-up resistors on I2C lines. The I2C interface can be enabled over the I2C SEL jumper. While disabled, you can use the WUP pin to indicate the WakeUp activity state of the module; otherwise, the WUP function is unavailable. The module can be reset over the RST pin. The generic application activity is indicated over the APP pin with a logic LOW state when active. If the Wireless Encrypted Setup JP2 jumper is closed, you can enable the WES client over the WES pin. This Click board™ can be operated only with a 3.3V logic voltage level. The board must perform appropriate logic voltage level conversion before using MCUs with different logic levels. Also, it comes equipped with a library containing functions and an example code that can be used as a reference for further development.

NeoMesh Click - 915MHz hardware overview image

Features overview

Development board

PIC Clicker is a compact starter development board that brings the flexibility of add-on Click boards™ to your favorite microcontroller, making it a perfect starter kit for implementing your ideas. It has an onboard 8-bit PIC microcontroller, the PIC18F47J53 from Microchip, a USB connector, LED indicators, buttons, a mikroProg connector, and a header for interfacing with external electronics. Thanks to its compact design with clear and easy-recognizable silkscreen markings, it provides a fluid and immersive working experience, allowing access anywhere and under any

circumstances. Each part of the PIC Clicker development kit contains the components necessary for the most efficient operation of the same board. In addition to the possibility of choosing the PIC Clicker programming method, using USB HID mikroBootloader, or through an external mikroProg connector for PIC, dsPIC, or PIC32 programmer, the Clicker board also includes a clean and regulated power supply module for the development kit. The USB Mini-B connection can provide up to 500mA of current, which is more than enough to operate all onboard and additional

modules. All communication methods that mikroBUS™ itself supports are on this board, including the well-established mikroBUS™ socket, reset button, and several buttons and LED indicators. PIC Clicker is an integral part of the Mikroe ecosystem, allowing you to create a new application in minutes. Natively supported by Mikroe software tools, it covers many aspects of prototyping thanks to a considerable number of different Click boards™ (over a thousand boards), the number of which is growing every day.

PIC clicker double side image

Microcontroller Overview

MCU Card / MCU

default

Architecture

PIC

MCU Memory (KB)

128

Silicon Vendor

Microchip

Pin count

44

RAM (Bytes)

3800

You complete me!

Accessories

Rubber Antenna GSM/GPRS Right Angle is the perfect companion for all GSM Click boards™ in our extensive lineup. This specialized antenna is designed to optimize your wireless connectivity with impressive features. With a wide frequency range spanning 824-894/1710-1990MHz or 890-960/1710-1890MHz, it can handle various frequency bands, ensuring a seamless and reliable connection. The antenna boasts an impedance of 50 Ohms and a gain of 2dB, enhancing signal reception and transmission. Its 70/180MHz bandwidth provides flexibility for diverse applications. The vertical polarization further enhances its performance. With a maximum input power capacity of 50W, this antenna ensures robust communication even under demanding conditions. Measuring a compact 50mm in length and featuring an SMA male connector, the Rubber Antenna GSM/GPRS Right Angle is a versatile and compact solution for your wireless communication needs.

NeoMesh Click - 915MHz accessories 1 image

IPEX-SMA cable is a type of RF (radio frequency) cable assembly. "IPEX" refers to the IPEX connector, a miniature coaxial connector commonly used in small electronic devices. "SMA" stands for SubMiniature Version A and is another coaxial connector commonly used in RF applications. An IPEX-SMA cable assembly has an IPEX connector on one end and an SMA connector on the other, allowing it to connect devices or components that use these specific connectors. These cables are often used in applications like WiFi or cellular antennas, GPS modules, and other RF communication systems where a reliable and low-loss connection is required.

NeoMesh Click - 915MHz accessories 2 image

Used MCU Pins

mikroBUS™ mapper

Generic APP Activity
RA2
AN
Reset / ID SEL
RB2
RST
WES Client / ID COMM
RB3
CS
NC
NC
SCK
NC
NC
MISO
NC
NC
MOSI
Power Supply
3.3V
3.3V
Ground
GND
GND
UART CTS
RC6
PWM
WakeUp Time
RD4
INT
UART TX
RD6
TX
UART RX
RD5
RX
I2C Clock
RD0
SCL
I2C Data
RD1
SDA
NC
NC
5V
Ground
GND
GND
1

Take a closer look

Schematic

NeoMesh Click - 915MHz Schematic schematic

Step by step

Project assembly

PIC clicker front image hardware assembly

Start by selecting your development board and Click board™. Begin with the PIC clicker as your development board.

PIC clicker front image hardware assembly
GNSS2 Click front image hardware assembly
Prog-cut hardware assembly
GNSS2 Click complete accessories setup image hardware assembly
Mini B Connector Clicker Access - upright/background hardware assembly
Necto image step 2 hardware assembly
Necto image step 3 hardware assembly
Necto image step 4 hardware assembly
Necto image step 5 hardware assembly
Necto image step 6 hardware assembly
Necto_MCU_Select_PICPLC16 hardware assembly
Necto No Display image step 8 hardware assembly
Necto image step 9 hardware assembly
Necto image step 10 hardware assembly
Debug Image Necto Step hardware assembly

Track your results in real time

Application Output

After loading the code example, pressing the "DEBUG" button builds and programs it on the selected setup.

Application Output Step 1

After programming is completed, a header with buttons for various actions available in the IDE appears. By clicking the green "PLAY "button, we start reading the results achieved with Click board™.

Application Output Step 3

Upon completion of programming, the Application Output tab is automatically opened, where the achieved result can be read. In case of an inability to perform the Debug function, check if a proper connection between the MCU used by the setup and the CODEGRIP programmer has been established. A detailed explanation of the CODEGRIP-board connection can be found in the CODEGRIP User Manual. Please find it in the RESOURCES section.

Application Output Step 4

Software Support

Library Description

This library contains API for NeoMesh Click - 915MHz driver.

Key functions:

  • neomesh915mhz_send_aapi_frame - This function sends a desired AAPI frame by using UART serial interface.

  • neomesh915mhz_read_aapi_frame - This function reads an AAPI frame by using UART serial interface.

  • neomesh915mhz_send_sapi_frame - This function sends a desired SAPI frame by using UART serial interface.

Open Source

Code example

This example can be found in NECTO Studio. Feel free to download the code, or you can copy the code below.

/*!
 * @file main.c
 * @brief NeoMesh 915MHz Click Example.
 *
 * # Description
 * This example demonstrates the use of NeoMesh 915MHz click board by showing
 * the communication between the two click boards.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initializes the driver and configures the click board for the selected
 * application mode.
 *
 * ## Application Task
 * One click board should be set to originator mode and the others to receiver 1 or 2.
 * If the SINGLE_RECEIVER_MODE is enabled, the originator device sends a desired message
 * to RECEIVER_1 node and waits for an acknowledge response, otherwise it sends the same
 * message to both RECEIVER_1 and RECEIVER_2 nodes. The receiver devices reads and parses
 * all incoming AAPI frames and displays them on the USB UART.
 *
 * @author Stefan Filipovic
 *
 */

#include "board.h"
#include "log.h"
#include "neomesh915mhz.h"

// Comment out the line below to add the APP_RECEIVER_2 to the APP_ORIGINATOR example.
#define SINGLE_RECEIVER_MODE

// Demo aplication selection macros
#define APP_ORIGINATOR              0
#define APP_RECEIVER_1              1
#define APP_RECEIVER_2              2
#define DEMO_APP                    APP_ORIGINATOR

// Text message to send in the originator mode
#define DEMO_TEXT_MESSAGE           "MIKROE-NeoMesh"
#define DEFAULT_PORT                0

// Node ID macros
#define NODE_ID_ORIGINATOR          0x0100u
#define NODE_ID_RECEIVER_1          0x0020u
#define NODE_ID_RECEIVER_2          0x0021u

static neomesh915mhz_t neomesh915mhz;
static log_t logger;
static neomesh915mhz_aapi_frame_t aapi_frame;
static neomesh915mhz_sapi_frame_t sapi_frame;

/**
 * @brief NeoMesh 915MHz parse aapi rsp function.
 * @details This function reads and parses AAPI responses until an expected response is received.
 * @param[in] exp_rsp : Expected AAPI response.
 * @return @li @c  0 - Success,
 *         @li @c -1 - Error, no expected response is received,
 * See #err_t definition for detailed explanation.
 * @note None.
 */
static err_t neomesh915mhz_parse_aapi_rsp ( uint8_t exp_rsp );

/**
 * @brief NeoMesh 915MHz parse sapi rsp function.
 * @details This function reads and parses SAPI responses until an expected response is received.
 * @param[in] exp_rsp : Expected SAPI response.
 * @return @li @c  0 - Success,
 *         @li @c -1 - Error, no expected response is received,
 * See #err_t definition for detailed explanation.
 * @note None.
 */
static err_t neomesh915mhz_parse_sapi_rsp ( uint16_t exp_rsp );

void application_init ( void )
{
    log_cfg_t log_cfg;  /**< Logger config object. */
    neomesh915mhz_cfg_t neomesh915mhz_cfg;  /**< Click config object. */

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, " Application Init " );

    // Click initialization.
    neomesh915mhz_cfg_setup( &neomesh915mhz_cfg );
    NEOMESH915MHZ_MAP_MIKROBUS( neomesh915mhz_cfg, MIKROBUS_1 );
    if ( UART_ERROR == neomesh915mhz_init( &neomesh915mhz, &neomesh915mhz_cfg ) )
    {
        log_error( &logger, " Communication init." );
        for ( ; ; );
    }

    log_printf( &logger, "\r\n Enable SAPI over AAPI\r\n" );
    aapi_frame.cmd = NEOMESH915MHZ_CMD_SAPI_TO_AAPI;
    aapi_frame.len = 0;
    neomesh915mhz_send_aapi_frame ( &neomesh915mhz, &aapi_frame );
    neomesh915mhz_parse_sapi_rsp ( NEOMESH915MHZ_SAPI_RSP_BOOTLOADER_START );

    log_printf( &logger, "\r\n Login with password\r\n" );
    sapi_frame.cmd = NEOMESH915MHZ_SAPI_CMD_LOGIN;
    sapi_frame.len = 5;
    sapi_frame.payload[ 0 ] = NEOMESH915MHZ_SAPI_LOGIN_PASSWORD_0;
    sapi_frame.payload[ 1 ] = NEOMESH915MHZ_SAPI_LOGIN_PASSWORD_1;
    sapi_frame.payload[ 2 ] = NEOMESH915MHZ_SAPI_LOGIN_PASSWORD_2;
    sapi_frame.payload[ 3 ] = NEOMESH915MHZ_SAPI_LOGIN_PASSWORD_3;
    sapi_frame.payload[ 4 ] = NEOMESH915MHZ_SAPI_LOGIN_PASSWORD_4;
    neomesh915mhz_send_sapi_frame ( &neomesh915mhz, &sapi_frame );
    neomesh915mhz_parse_sapi_rsp ( NEOMESH915MHZ_SAPI_RSP_OK );

    log_printf( &logger, "\r\n Set NODE ID to: " );
    sapi_frame.cmd = NEOMESH915MHZ_SAPI_CMD_SET_SETTING;
    sapi_frame.len = 3;
    sapi_frame.payload[ 0 ] = NEOMESH915MHZ_SAPI_SETTINGS_ID_NODE_ID;
#if ( DEMO_APP == APP_RECEIVER_1 )
    log_printf( &logger, "%.4X\r\n", ( uint16_t ) NODE_ID_RECEIVER_1 );
    sapi_frame.payload[ 1 ] = ( uint8_t ) ( ( NODE_ID_RECEIVER_1 >> 8 ) & 0xFF );
    sapi_frame.payload[ 2 ] = ( uint8_t ) ( NODE_ID_RECEIVER_1 & 0xFF );
#elif ( DEMO_APP == APP_RECEIVER_2 )
    log_printf( &logger, "%.4X\r\n", ( uint16_t ) NODE_ID_RECEIVER_2 );
    sapi_frame.payload[ 1 ] = ( uint8_t ) ( ( NODE_ID_RECEIVER_2 >> 8 ) & 0xFF );
    sapi_frame.payload[ 2 ] = ( uint8_t ) ( NODE_ID_RECEIVER_2 & 0xFF );
#elif ( DEMO_APP == APP_ORIGINATOR )
    log_printf( &logger, "%.4X\r\n", ( uint16_t ) NODE_ID_ORIGINATOR );
    sapi_frame.payload[ 1 ] = ( uint8_t ) ( ( NODE_ID_ORIGINATOR >> 8 ) & 0xFF );
    sapi_frame.payload[ 2 ] = ( uint8_t ) ( NODE_ID_ORIGINATOR & 0xFF );
#endif
    neomesh915mhz_send_sapi_frame ( &neomesh915mhz, &sapi_frame );
    neomesh915mhz_parse_sapi_rsp ( NEOMESH915MHZ_SAPI_RSP_OK );

    log_printf( &logger, "\r\n Commit settings\r\n" );
    sapi_frame.cmd = NEOMESH915MHZ_SAPI_CMD_COMMIT_SETTINGS;
    sapi_frame.len = 0;
    neomesh915mhz_send_sapi_frame ( &neomesh915mhz, &sapi_frame );
    neomesh915mhz_parse_sapi_rsp ( NEOMESH915MHZ_SAPI_RSP_OK );

    log_printf( &logger, "\r\n Start protocol stack\r\n" );
    sapi_frame.cmd = NEOMESH915MHZ_SAPI_CMD_START_PROTOCOL_STACK;
    sapi_frame.len = 0;
    neomesh915mhz_send_sapi_frame ( &neomesh915mhz, &sapi_frame );
    neomesh915mhz_parse_sapi_rsp ( NEOMESH915MHZ_SAPI_RSP_PROTOCOL_STACK_START );
    // Wait for the device to actually switch back to application layer
    while ( !neomesh915mhz_get_cts_pin ( &neomesh915mhz ) );

    log_printf( &logger, "\r\n Get NODE info\r\n" );
    aapi_frame.cmd = NEOMESH915MHZ_CMD_NODE_INFO;
    aapi_frame.len = 0;
    neomesh915mhz_send_aapi_frame ( &neomesh915mhz, &aapi_frame );
    neomesh915mhz_parse_aapi_rsp ( NEOMESH915MHZ_RSP_NODE_INFO );

    log_printf( &logger, "\r\n Get neighbour list\r\n" );
    aapi_frame.cmd = NEOMESH915MHZ_CMD_NEIGHBOUR_LIST;
    aapi_frame.len = 0;
    neomesh915mhz_send_aapi_frame ( &neomesh915mhz, &aapi_frame );
    neomesh915mhz_parse_aapi_rsp ( NEOMESH915MHZ_RSP_NEIGHBOUR_LIST );

#if ( DEMO_APP == APP_RECEIVER_1 )
    log_printf( &logger, "\r\n Application Mode: Receiver 1\r\n" );
#elif ( DEMO_APP == APP_RECEIVER_2 )
    log_printf( &logger, "\r\n Application Mode: Receiver 2\r\n" );
#elif ( DEMO_APP == APP_ORIGINATOR )
    log_printf( &logger, "\r\n Application Mode: Originator\r\n" );
#else
    #error "Selected application mode is not supported!"
#endif

    log_info( &logger, " Application Task " );
}

void application_task ( void )
{
#if ( DEMO_APP == APP_ORIGINATOR )
    log_printf( &logger, "\r\n Send message to node: %.4X\r\n", ( uint16_t ) NODE_ID_RECEIVER_1 );
    aapi_frame.cmd = NEOMESH915MHZ_CMD_ACK_SEND;
    aapi_frame.len = 3 + strlen ( DEMO_TEXT_MESSAGE );
    aapi_frame.payload[ 0 ] = ( uint8_t ) ( ( NODE_ID_RECEIVER_1 >> 8 ) & 0xFF );
    aapi_frame.payload[ 1 ] = ( uint8_t ) ( NODE_ID_RECEIVER_1 & 0xFF );
    aapi_frame.payload[ 2 ] = DEFAULT_PORT;
    strcpy ( &aapi_frame.payload[ 3 ], DEMO_TEXT_MESSAGE );
    if ( NEOMESH915MHZ_OK == neomesh915mhz_send_aapi_frame ( &neomesh915mhz, &aapi_frame ) )
    {
        neomesh915mhz_parse_aapi_rsp ( NEOMESH915MHZ_RSP_ACK );
    }
    #ifndef SINGLE_RECEIVER_MODE
        log_printf( &logger, "\r\n Send message to node: %.4X\r\n", ( uint16_t ) NODE_ID_RECEIVER_2 );
        aapi_frame.cmd = NEOMESH915MHZ_CMD_ACK_SEND;
        aapi_frame.len = 3 + strlen ( DEMO_TEXT_MESSAGE );
        aapi_frame.payload[ 0 ] = ( uint8_t ) ( ( NODE_ID_RECEIVER_2 >> 8 ) & 0xFF );
        aapi_frame.payload[ 1 ] = ( uint8_t ) ( NODE_ID_RECEIVER_2 & 0xFF );
        aapi_frame.payload[ 2 ] = DEFAULT_PORT;
        strcpy ( &aapi_frame.payload[ 3 ], DEMO_TEXT_MESSAGE );
        if ( NEOMESH915MHZ_OK == neomesh915mhz_send_aapi_frame ( &neomesh915mhz, &aapi_frame ) )
        {
            neomesh915mhz_parse_aapi_rsp ( NEOMESH915MHZ_RSP_ACK );
        }
    #endif
#else
   neomesh915mhz_parse_aapi_rsp ( NULL );
#endif
}

void main ( void )
{
    application_init( );

    for ( ; ; )
    {
        application_task( );
    }
}

static err_t neomesh915mhz_parse_aapi_rsp ( uint8_t exp_rsp )
{
    while ( NEOMESH915MHZ_OK == neomesh915mhz_read_aapi_frame ( &neomesh915mhz, &aapi_frame ) )
    {
        switch ( aapi_frame.cmd )
        {
            case NEOMESH915MHZ_RSP_ACK:
            {
                log_printf( &logger, "---- ACK ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_NACK:
            {
                log_printf( &logger, "---- NACK ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_ACK_HOST:
            {
                log_printf( &logger, "---- ACK HOST DATA ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Packet Age: %.3f sec\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 2 ] << 8 ) |
                              aapi_frame.payload[ 3 ] ) * 0.125f );
                log_printf( &logger, " Port: %u\r\n", aapi_frame.payload[ 4 ] );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 5; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                aapi_frame.payload[ aapi_frame.len ] = 0;
                log_printf( &logger, " Payload (string): %s\r\n\n", &aapi_frame.payload[ 5 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_ACK_HOST_HAPA:
            {
                log_printf( &logger, "---- ACK HOST DATA HAPA ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Packet Age: %.3f sec\r\n",
                            ( ( ( uint32_t ) aapi_frame.payload[ 2 ] << 24 ) |
                              ( ( uint32_t ) aapi_frame.payload[ 3 ] << 16 ) |
                              ( ( uint16_t ) aapi_frame.payload[ 4 ] << 8 ) |
                              aapi_frame.payload[ 5 ] ) * pow ( 2, -19 ) );
                log_printf( &logger, " Port: %u\r\n", aapi_frame.payload[ 6 ] );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 7; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_RSP_NACK_HOST:
            {
                log_printf( &logger, "---- NACK HOST DATA ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Packet Age: %.3f sec\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 2 ] << 8 ) |
                              aapi_frame.payload[ 3 ] ) * 0.125f );
                log_printf( &logger, " Port: %u\r\n", aapi_frame.payload[ 4 ] );
                log_printf( &logger, " Sequence number: %u\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 5 ] << 8 ) |
                              aapi_frame.payload[ 6 ] ) & 0x0FFFu );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 7; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_RSP_NACK_HOST_HAPA:
            {
                log_printf( &logger, "---- NACK HOST DATA HAPA ----\r\n" );
                log_printf( &logger, " Originator ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Packet Age: %.3f sec\r\n",
                            ( ( ( uint32_t ) aapi_frame.payload[ 2 ] << 24 ) |
                              ( ( uint32_t ) aapi_frame.payload[ 3 ] << 16 ) |
                              ( ( uint16_t ) aapi_frame.payload[ 4 ] << 8 ) |
                              aapi_frame.payload[ 5 ] ) * pow ( 2, -19 ) );
                log_printf( &logger, " Port: %u\r\n", aapi_frame.payload[ 6 ] );
                log_printf( &logger, " Sequence number: %u\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 7 ] << 8 ) |
                              aapi_frame.payload[ 8 ] ) & 0x0FFFu );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 9; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_RSP_NACK_SEND:
            {
                log_printf( &logger, "---- NACK SEND ----\r\n" );
                log_printf( &logger, " Destination ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Sequence number: %u\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 2 ] << 8 ) |
                              aapi_frame.payload[ 3 ] ) & 0x0FFFu );
                break;
            }
            case NEOMESH915MHZ_RSP_NACK_DROP:
            {
                log_printf( &logger, "---- NACK DROP ----\r\n" );
                log_printf( &logger, " Destination ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Sequence number: %u\r\n",
                            ( ( ( uint16_t ) aapi_frame.payload[ 2 ] << 8 ) |
                              aapi_frame.payload[ 3 ] ) & 0x0FFFu );
                break;
            }
            case NEOMESH915MHZ_RSP_NODE_INFO:
            {
                log_printf( &logger, "---- NODE INFO ----\r\n" );
                log_printf( &logger, " Node ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Unique ID: %.2X%.2X%.2X%.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 2 ], ( uint16_t ) aapi_frame.payload[ 3 ],
                            ( uint16_t ) aapi_frame.payload[ 4 ], ( uint16_t ) aapi_frame.payload[ 5 ],
                            ( uint16_t ) aapi_frame.payload[ 6 ] );
                log_printf( &logger, " Type: %.2X\r\n", ( uint16_t ) aapi_frame.payload[ 7 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_NEIGHBOUR_LIST:
            {
                log_printf( &logger, "---- NEIGHBOUR LIST ----\r\n" );
                for ( uint8_t cnt = 0; cnt < aapi_frame.len; cnt += 3 )
                {
                    log_printf( &logger, " %u# -> ", ( uint16_t ) ( ( cnt / 3 ) + 1 ) );
                    if ( ( 0xFF != aapi_frame.payload[ cnt ] ) &&
                         ( 0xFF != aapi_frame.payload[ cnt + 1 ] ) )
                    {
                        log_printf( &logger, "Node ID: %.2X%.2X, RSSI: -%u dBm\r\n",
                                    ( uint16_t ) aapi_frame.payload[ cnt ],
                                    ( uint16_t ) aapi_frame.payload[ cnt + 1 ],
                                    ( uint16_t ) aapi_frame.payload[ cnt + 2 ] );
                    }
                    else
                    {
                        log_printf( &logger, "N/A\r\n" );
                    }
                }
                break;
            }
            case NEOMESH915MHZ_RSP_NETWORK_COMMAND:
            {
                log_printf( &logger, "---- NETWORK COMMAND ----\r\n" );
                log_printf( &logger, " Node ID: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ] );
                log_printf( &logger, " Command: %.2X\r\n", ( uint16_t ) aapi_frame.payload[ 2 ] );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 3; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_RSP_ROUTE_INFO:
            {
                log_printf( &logger, "---- ROUTE INFO ----\r\n" );
                log_printf( &logger, " Bit Mask: " );
                for ( uint8_t cnt = 0; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_RSP_WES_STATUS:
            {
                log_printf( &logger, "---- WES STATUS ----\r\n" );
                if ( !aapi_frame.payload[ 0 ] )
                {
                    log_printf( &logger, " WES stopped\r\n" );
                }
                else
                {
                    log_printf( &logger, " WES server running\r\n" );
                }
                break;
            }
            case NEOMESH915MHZ_RSP_WES_SETUP:
            {
                log_printf( &logger, "---- WES SETUP ----\r\n" );
                log_printf( &logger, " Unique ID: %.2X%.2X%.2X%.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 0 ], ( uint16_t ) aapi_frame.payload[ 1 ],
                            ( uint16_t ) aapi_frame.payload[ 2 ], ( uint16_t ) aapi_frame.payload[ 3 ],
                            ( uint16_t ) aapi_frame.payload[ 4 ] );
                log_printf( &logger, " Type: %.2X\r\n", ( uint16_t ) aapi_frame.payload[ 5 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_GET_SW_VERSION:
            {
                log_printf( &logger, "---- SW VERSION ----\r\n" );
                log_printf( &logger, " HW/SW Type: %.2X\r\n", ( uint16_t ) aapi_frame.payload[ 0 ] );
                log_printf( &logger, " NeoMesh Version: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 1 ], ( uint16_t ) aapi_frame.payload[ 2 ] );
                log_printf( &logger, " Bootloader Version: %.2X%.2X\r\n",
                            ( uint16_t ) aapi_frame.payload[ 3 ], ( uint16_t ) aapi_frame.payload[ 4 ] );
                break;
            }
            case NEOMESH915MHZ_RSP_ALT_MODE:
            {
                log_printf( &logger, "---- ALT MODE ----\r\n" );
                if ( !aapi_frame.payload[ 0 ] )
                {
                    log_printf( &logger, " Network in Normal mode\r\n" );
                }
                else
                {
                    log_printf( &logger, " Network in Alternate mode\r\n" );
                }
                break;
            }
            default:
            {
                log_printf( &logger, "---- RESPONSE ----\r\n" );
                log_printf( &logger, " CMD: 0x%.2X\r\n", ( uint16_t ) aapi_frame.cmd );
                log_printf( &logger, " LEN: %u\r\n", ( uint16_t ) aapi_frame.len );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 0; cnt < aapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) aapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
        }
        if ( exp_rsp == aapi_frame.cmd )
        {
            return NEOMESH915MHZ_OK;
        }
    }
    return NEOMESH915MHZ_ERROR;
}

static err_t neomesh915mhz_parse_sapi_rsp ( uint16_t exp_rsp )
{
    while ( NEOMESH915MHZ_OK == neomesh915mhz_read_sapi_frame ( &neomesh915mhz, &sapi_frame ) )
    {
        switch ( sapi_frame.cmd )
        {
            case NEOMESH915MHZ_SAPI_RSP_OK:
            {
                log_printf( &logger, "---- OK ----\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_ERROR:
            {
                log_printf( &logger, "---- ERROR ----\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_BOOTLOADER_START:
            {
                log_printf( &logger, "---- Bootloader STARTED ----\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_PROTOCOL_STACK_START:
            {
                log_printf( &logger, "---- Protocol Stack STARTED ----\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_PROTOCOL_STACK_ERROR:
            {
                log_printf( &logger, "---- Protocol Stack ERROR ----\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_SETTINGS_LIST_OUTPUT:
            {
                log_printf( &logger, "---- Settings List Output ----\r\n" );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 0; cnt < sapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) sapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_SETTINGS_VALUE:
            {
                log_printf( &logger, "---- Settings Value ----\r\n" );
                log_printf( &logger, " Payload: " );
                for ( uint8_t cnt = 0; cnt < sapi_frame.len; cnt++ )
                {
                    log_printf( &logger, "%.2X ", ( uint16_t ) sapi_frame.payload[ cnt ] );
                }
                log_printf( &logger, "\r\n" );
                break;
            }
            case NEOMESH915MHZ_SAPI_RSP_RESET:
            {
                log_printf( &logger, "---- Reset EVENT ----\r\n" );
                break;
            }
            default:
            {
                log_printf( &logger, "---- RESPONSE ----\r\n" );
                log_printf( &logger, " CMD: 0x%.4X\r\n", ( uint16_t ) sapi_frame.cmd );
                log_printf( &logger, " PLEN: %u\r\n", ( uint16_t ) sapi_frame.len );
                if ( sapi_frame.len )
                {
                    log_printf( &logger, " Payload: " );
                    for ( uint8_t cnt = 0; cnt < sapi_frame.len; cnt++ )
                    {
                        log_printf( &logger, "%.2X ", ( uint16_t ) sapi_frame.payload[ cnt ] );
                    }
                    log_printf( &logger, "\r\n" );
                }
                break;
            }
        }
        if ( exp_rsp == sapi_frame.cmd )
        {
            return NEOMESH915MHZ_OK;
        }
    }
    return NEOMESH915MHZ_ERROR;
}

// ------------------------------------------------------------------------ END

Additional Support

Resources
