Accurate water chemistry analysis solution compatible with conductivity probes of various conductance levels (from K 0.01 to K 10.2)
A
A
Hardware Overview
How does it work?
EZO Carrier Click - Conductivity is based on the EZO-EC™, an ISO 7888 compliant embedded conductivity circuit board from Atlas Scientific. This is a versatile and accurate solution for measuring conductivity, salinity, and Total Dissolved Solids (TDS) in various applications from chemical production to hydroponics. With a conductivity range of 0.07 to over 500,000 μS/cm, it can also accurately measure salinity up to 42 PSU (ppt), TDS as ppm, and specific gravity of seawater between 1.00 and 1.300. This advanced module offers the precision and functionality comparable to high-end bench-top conductivity meters, making it an ideal choice for embedding into projects that require reliable water chemistry measurements. Boasting an accuracy of +/- 2% and a quick EC reading time of 600ms, the EZO-EC™ supports probes ranging from K 0.01 to K 10.2 of any brand. It allows for both two-point and three-point
calibration, ensuring precise measurements. Additionally, it features temperature compensation for more accurate readings across various conditions. This circuit is a very sensitive device, and its sensitivity gives it accuracy. That’s why the EZO-EC™ needs to be isolated from the host MCU; therefore, this Click™ board comes with the Si8400AB, a bidirectional isolator from Skyworks. The isolator provides standard bidirectional and I2C communication with a clock frequency of up to 1.7MHz. So, to eliminate the electrical noise, besides the Si8400AB isolator, the power supply voltage is also isolated. For this purpose, this Click™ board is equipped with the ROE-0505S, a DC/DC converter from Recom. EZO Carrier Click - Conductivity can use a standard 2-wire UART interface to communicate with the host MCU with the default baud rate of 9600bps. While using the UART interface, you can use the library we provide
or a simple ASCII set of commands. You can also choose a standard 2-wire I2C interface over the COMM SEL jumpers. From calibration to timed readings, the Atlas Scientific EZO-EC™ circuit is a drop-in solution to a complex measurement. It features sleep mode, continuous operation, find function, export/import calibration, on-module status LED, and many more features detailed and described in the attached datasheet. This Click board™ can operate with either 3.3V or 5V logic voltage levels selected via the VCC SEL jumper. This way, both 3.3V and 5V capable MCUs can use the communication lines properly. Also, this Click board™ comes equipped with a library containing easy-to-use functions and an example code that can be used as a reference for further development.
Features overview
Development board
PIC18F57Q43 Curiosity Nano evaluation kit is a cutting-edge hardware platform designed to evaluate microcontrollers within the PIC18-Q43 family. Central to its design is the inclusion of the powerful PIC18F57Q43 microcontroller (MCU), offering advanced functionalities and robust performance. Key features of this evaluation kit include a yellow user LED and a responsive
mechanical user switch, providing seamless interaction and testing. The provision for a 32.768kHz crystal footprint ensures precision timing capabilities. With an onboard debugger boasting a green power and status LED, programming and debugging become intuitive and efficient. Further enhancing its utility is the Virtual serial port (CDC) and a debug GPIO channel (DGI
GPIO), offering extensive connectivity options. Powered via USB, this kit boasts an adjustable target voltage feature facilitated by the MIC5353 LDO regulator, ensuring stable operation with an output voltage ranging from 1.8V to 5.1V, with a maximum output current of 500mA, subject to ambient temperature and voltage constraints.
Microcontroller Overview
MCU Card / MCU
Architecture
PIC
MCU Memory (KB)
128
Silicon Vendor
Microchip
Pin count
48
RAM (Bytes)
8196
You complete me!
Accessories
Curiosity Nano Base for Click boards is a versatile hardware extension platform created to streamline the integration between Curiosity Nano kits and extension boards, tailored explicitly for the mikroBUS™-standardized Click boards and Xplained Pro extension boards. This innovative base board (shield) offers seamless connectivity and expansion possibilities, simplifying experimentation and development. Key features include USB power compatibility from the Curiosity Nano kit, alongside an alternative external power input option for enhanced flexibility. The onboard Li-Ion/LiPo charger and management circuit ensure smooth operation for battery-powered applications, simplifying usage and management. Moreover, the base incorporates a fixed 3.3V PSU dedicated to target and mikroBUS™ power rails, alongside a fixed 5.0V boost converter catering to 5V power rails of mikroBUS™ sockets, providing stable power delivery for various connected devices.
The Atlas Scientific conductivity probe, known as Probe K, stands out for its stable and precise readings across a wide range of conductivity. Free from fringe effects, it ensures accuracy within a range of 5 to 200,000μS/cm, with an impressive accuracy of ±2%. Responding swiftly, it achieves 90% accuracy in just 1 second, making it ideal for real-time monitoring applications. With a broad temperature range from 1 to 110°C, it can withstand diverse environmental conditions. Its robust construction allows for a maximum pressure of 3,447kPa (500PSI) and a maximum depth of 352 meters (1,157 feet). A 1-meter cable provides installation flexibility. Probe K boasts a long recalibration interval of approximately ten years, aligning with its equally impressive life expectancy. Probe K ensures reliable conductivity measurements for a decade and beyond with these features.
Used MCU Pins
mikroBUS™ mapper
Take a closer look
Schematic
Step by step
Project assembly
Track your results in real time
Application Output
After loading the code example, pressing the "DEBUG" button builds and programs it on the selected setup.
After programming is completed, a header with buttons for various actions available in the IDE appears. By clicking the green "PLAY "button, we start reading the results achieved with Click board™.
Upon completion of programming, the Application Output tab is automatically opened, where the achieved result can be read. In case of an inability to perform the Debug function, check if a proper connection between the MCU used by the setup and the CODEGRIP programmer has been established. A detailed explanation of the CODEGRIP-board connection can be found in the CODEGRIP User Manual. Please find it in the RESOURCES section.
Software Support
Library Description
This library contains API for EZO Carrier Click - Conductivity driver.
Key functions:
ezocarrierec_send_cmd
- Send command functionezocarrierec_send_cmd_with_par
- Send command function with parameterezocarrierec_send_cmd_check
- Check the sent command
Open Source
Code example
This example can be found in NECTO Studio. Feel free to download the code, or you can copy the code below.
/*!
* @file main.c
* @brief EZO Carrier EC Click Example.
*
* # Description
* This example demonstrates the use of EZO Carrier EC click board by processing
* the incoming data and displaying them on the USB UART.
*
* The demo application is composed of two sections :
*
* ## Application Init
* Initializes the driver, performs the click default factory reset, and single point calibration.
*
* ## Application Task
* Reads and processes all incoming conductivity data from the probe, and displays them on the USB UART in uS.
*
* ## Additional Function
* - static void ezocarrierec_clear_app_buf ( void )
* - static void ezocarrierec_log_app_buf ( void )
* - static err_t ezocarrierec_process ( ezocarrierec_t *ctx )
* - static err_t ezocarrierec_rsp_check ( ezocarrierec_t *ctx, uint8_t *rsp )
* - static void ezocarrierec_error_check ( err_t error_flag )
*
* @author Stefan Ilic
*
*/
#include "board.h"
#include "log.h"
#include "ezocarrierec.h"
// Application buffer size
#define APP_BUFFER_SIZE 200
#define PROCESS_BUFFER_SIZE 200
static ezocarrierec_t ezocarrierec;
static log_t logger;
static uint8_t app_buf[ APP_BUFFER_SIZE ] = { 0 };
static int32_t app_buf_len = 0;
static err_t error_flag;
/**
* @brief EZO Carrier EC clearing application buffer.
* @details This function clears memory of application buffer and reset its length.
* @note None.
*/
static void ezocarrierec_clear_app_buf ( void );
/**
* @brief EZO Carrier EC log application buffer.
* @details This function logs data from application buffer to USB UART.
* @note None.
*/
static void ezocarrierec_log_app_buf ( void );
/**
* @brief EZO Carrier EC data reading function.
* @details This function reads data from device and concatenates data to application buffer.
* @param[in] ctx : Click context object.
* See #ezocarrierec_t object definition for detailed explanation.
* @return @li @c 0 - Read some data.
* @li @c -1 - Nothing is read.
* See #err_t definition for detailed explanation.
* @note None.
*/
static err_t ezocarrierec_process ( ezocarrierec_t *ctx );
/**
* @brief Response check.
* @details This function checks for response and
* returns the status of response.
* @param[in] rsp Expected response.
* @return @li @c 0 - OK response.
* @li @c -1 - Error response.
* @li @c -2 - Timeout error.
* See #err_t definition for detailed explanation.
*/
static err_t ezocarrierec_rsp_check ( ezocarrierec_t *ctx, uint8_t *rsp );
/**
* @brief Check for errors.
* @details This function checks for different types of
* errors and logs them on UART or logs the response if no errors occured.
* @param[in] error_flag Error flag to check.
*/
static void ezocarrierec_error_check ( err_t error_flag );
void application_init ( void )
{
log_cfg_t log_cfg; /**< Logger config object. */
ezocarrierec_cfg_t ezocarrierec_cfg; /**< Click config object. */
/**
* Logger initialization.
* Default baud rate: 115200
* Default log level: LOG_LEVEL_DEBUG
* @note If USB_UART_RX and USB_UART_TX
* are defined as HAL_PIN_NC, you will
* need to define them manually for log to work.
* See @b LOG_MAP_USB_UART macro definition for detailed explanation.
*/
LOG_MAP_USB_UART( log_cfg );
log_init( &logger, &log_cfg );
log_info( &logger, " Application Init " );
// Click initialization.
ezocarrierec_cfg_setup( &ezocarrierec_cfg );
EZOCARRIEREC_MAP_MIKROBUS( ezocarrierec_cfg, MIKROBUS_1 );
if ( UART_ERROR == ezocarrierec_init( &ezocarrierec, &ezocarrierec_cfg ) )
{
log_error( &logger, " Communication init." );
for ( ; ; );
}
log_printf( &logger, "Device status \r\n" );
ezocarrierec_send_cmd( &ezocarrierec, EZOCARRIEREC_CMD_STATUS );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
log_printf( &logger, "Factory reset \r\n" );
ezocarrierec_send_cmd( &ezocarrierec, EZOCARRIEREC_CMD_FACTORY );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_READY );
ezocarrierec_error_check( error_flag );
#define PROBE_TYPE "1.0"
log_printf( &logger, "Seting Probe type \r\n" );
ezocarrierec_send_cmd_with_par( &ezocarrierec, EZOCARRIEREC_CMD_SET_PROBE_TYPE, PROBE_TYPE );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
log_printf( &logger, "Device info \r\n" );
ezocarrierec_send_cmd( &ezocarrierec, EZOCARRIEREC_CMD_DEV_INFO );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
#define DRY_CALIBRATION "dry"
log_printf( &logger, "Dry calibration \r\n" );
ezocarrierec_send_cmd_with_par( &ezocarrierec, EZOCARRIEREC_CMD_CAL, DRY_CALIBRATION );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
uint8_t n_cnt = 0;
uint8_t last_reading[ APP_BUFFER_SIZE ] = { 0 };
ezocarrierec_clear_app_buf( );
ezocarrierec_send_cmd( &ezocarrierec, EZOCARRIEREC_CMD_SINGLE_READ );
ezocarrierec_process ( &ezocarrierec );
strcpy( last_reading, app_buf );
log_printf( &logger, "Single point calibration \r\n" );
log_printf( &logger, "Waiting for stable readings \r\n" );
while ( n_cnt <= 5 )
{
if ( EZOCARRIEREC_OK == ezocarrierec_process ( &ezocarrierec ) )
{
if ( 0 == strstr( app_buf, last_reading ) )
{
n_cnt++;
}
else
{
strcpy( last_reading, app_buf );
n_cnt = 0;
}
}
log_printf( &logger, "- " );
Delay_ms( 1000 );
ezocarrierec_clear_app_buf( );
}
#define CALIBRATION_VALUE "80"
log_printf( &logger, "Calibration \r\n" );
ezocarrierec_send_cmd_with_par( &ezocarrierec, EZOCARRIEREC_CMD_CAL, CALIBRATION_VALUE );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
#define DISABLE_CONT_READ "0"
log_printf( &logger, "Disable continuous reading mode \r\n" );
ezocarrierec_send_cmd_with_par( &ezocarrierec, EZOCARRIEREC_CMD_CONT_READ, DISABLE_CONT_READ );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
log_info( &logger, " Application Task " );
}
void application_task ( void )
{
log_printf( &logger, "Reading... \r\n" );
ezocarrierec_send_cmd( &ezocarrierec, EZOCARRIEREC_CMD_SINGLE_READ );
error_flag = ezocarrierec_rsp_check( &ezocarrierec, EZOCARRIEREC_RSP_OK );
ezocarrierec_error_check( error_flag );
Delay_ms( 5000 );
}
void main ( void )
{
application_init( );
for ( ; ; )
{
application_task( );
}
}
static void ezocarrierec_clear_app_buf ( void )
{
memset( app_buf, 0, app_buf_len );
app_buf_len = 0;
}
static void ezocarrierec_log_app_buf ( void )
{
for ( int32_t buf_cnt = 0; buf_cnt < app_buf_len; buf_cnt++ )
{
log_printf( &logger, "%c", app_buf[ buf_cnt ] );
}
}
static err_t ezocarrierec_process ( ezocarrierec_t *ctx )
{
uint8_t rx_buf[ PROCESS_BUFFER_SIZE ] = { 0 };
int32_t overflow_bytes = 0;
int32_t rx_cnt = 0;
int32_t rx_size = ezocarrierec_generic_read( ctx, rx_buf, PROCESS_BUFFER_SIZE );
if ( ( rx_size > 0 ) && ( rx_size <= APP_BUFFER_SIZE ) )
{
if ( ( app_buf_len + rx_size ) > APP_BUFFER_SIZE )
{
overflow_bytes = ( app_buf_len + rx_size ) - APP_BUFFER_SIZE;
app_buf_len = APP_BUFFER_SIZE - rx_size;
memmove ( app_buf, &app_buf[ overflow_bytes ], app_buf_len );
memset ( &app_buf[ app_buf_len ], 0, overflow_bytes );
}
for ( rx_cnt = 0; rx_cnt < rx_size; rx_cnt++ )
{
if ( rx_buf[ rx_cnt ] )
{
app_buf[ app_buf_len++ ] = rx_buf[ rx_cnt ];
}
}
return EZOCARRIEREC_OK;
}
return EZOCARRIEREC_ERROR;
}
static err_t ezocarrierec_rsp_check ( ezocarrierec_t *ctx, uint8_t *rsp )
{
uint32_t timeout_cnt = 0;
uint32_t timeout = 10000;
err_t error_flag = EZOCARRIEREC_OK;
ezocarrierec_clear_app_buf( );
while ( ( 0 == strstr( app_buf, rsp ) ) &&
( 0 == strstr( app_buf, EZOCARRIEREC_RSP_ERROR ) ) )
{
error_flag |= ezocarrierec_process( ctx );
if ( timeout_cnt++ > timeout )
{
ezocarrierec_clear_app_buf( );
return EZOCARRIEREC_ERROR_TIMEOUT;
}
Delay_ms( 1 );
}
Delay_ms( 100 );
error_flag |= ezocarrierec_process( ctx );
if ( strstr( app_buf, rsp ) )
{
return EZOCARRIEREC_OK;
}
else if ( strstr( app_buf, EZOCARRIEREC_RSP_ERROR ) )
{
return EZOCARRIEREC_ERROR;
}
else
{
return EZOCARRIEREC_ERROR;
}
}
static void ezocarrierec_error_check ( err_t error_flag )
{
switch ( error_flag )
{
case EZOCARRIEREC_OK:
{
ezocarrierec_log_app_buf( );
break;
}
case EZOCARRIEREC_ERROR:
{
log_error( &logger, " Error!" );
break;
}
case EZOCARRIEREC_ERROR_TIMEOUT:
{
log_error( &logger, " Timeout!" );
break;
}
default:
{
log_error( &logger, " Unknown!" );
break;
}
}
log_printf( &logger, "- - - - - - - - - - - - - - -\r\n" );
Delay_ms( 500 );
}
// ------------------------------------------------------------------------ END
