Integrate a rotary knob and visual indication into electronic projects with TLC5925 and ATmega328

User-friendly and visually informative input interface

Rotary B 2 Click with Arduino UNO Rev3

Published Feb 14, 2024

Click board™

Rotary B 2 Click

Dev Board

Arduino UNO Rev3

Compiler

NECTO Studio

MCU

ATmega328

Make your projects easier to use by adding a simple knob and clear visuals for better interaction

A

A

Hardware Overview

How does it work?

Rotary B 2 Click is based on the TLC5925, a low-power 16-channel constant-current LED sink driver from Texas Instruments that, combined with a high-quality rotary encoder from ALPS, the EC12D1564402, allows you to add a precision input knob to your design. The EC12D1564402 incremental rotary encoder is surrounded by a ring of 16 blue LEDs where a single rotation is divided into 15 discrete steps (in contrast to a potentiometer, a rotary encoder can be spun around continuously). The driver can control each LED individually, allowing various lighting effects to be programmed. The encoder outputs A and B signals (out of phase to each other) on the two mikroBUS™ lines, alongside the knob

push-button feature, which outputs through the interrupt line. The EC12D1564402 is a 15-pulse incremental rotary encoder with a push button. This encoder has unique mechanical specifications (debouncing time for its internal switches goes down to 2ms), and it can withstand a huge number of switching cycles, up to 30.000. The supporting debouncing circuitry allows contacts to settle before the output is triggered fully. Rotary B 2 Click uses a standard 4-wire SPI serial interface of the TLC5925 LED driver to communicate with the host MCU supporting clock frequency of up to 30MHz. Rotating the encoder, it outputs A and B signals (out of phase to each other) on the two mikroBUS™ lines, ENA and ENB

pins of the mikroBUS™ socket, alongside the push-button contact, which outputs through the SW pin (interrupt line) of the mikroBUS™ socket. Two SN74LVC1T45 single-bit dual-supply bus transceivers from Texas Instruments are used for logic-level translation. This Click board™ can operate with either 3.3V or 5V logic voltage levels selected via the VCC SEL jumper. This way, both 3.3V and 5V capable MCUs can use the communication lines properly. Also, this Click board™ comes equipped with a library containing easy-to-use functions and an example code that can be used as a reference for further development.

Rotary B 2 Click hardware overview image

Features overview

Development board

Arduino UNO is a versatile microcontroller board built around the ATmega328P chip. It offers extensive connectivity options for various projects, featuring 14 digital input/output pins, six of which are PWM-capable, along with six analog inputs. Its core components include a 16MHz ceramic resonator, a USB connection, a power jack, an

ICSP header, and a reset button, providing everything necessary to power and program the board. The Uno is ready to go, whether connected to a computer via USB or powered by an AC-to-DC adapter or battery. As the first USB Arduino board, it serves as the benchmark for the Arduino platform, with "Uno" symbolizing its status as the

first in a series. This name choice, meaning "one" in Italian, commemorates the launch of Arduino Software (IDE) 1.0. Initially introduced alongside version 1.0 of the Arduino Software (IDE), the Uno has since become the foundational model for subsequent Arduino releases, embodying the platform's evolution.

Arduino UNO Rev3 double side image

Microcontroller Overview

MCU Card / MCU

default

Architecture

AVR

MCU Memory (KB)

32

Silicon Vendor

Microchip

Pin count

32

RAM (Bytes)

2048

You complete me!

Accessories

Click Shield for Arduino UNO has two proprietary mikroBUS™ sockets, allowing all the Click board™ devices to be interfaced with the Arduino UNO board without effort. The Arduino Uno, a microcontroller board based on the ATmega328P, provides an affordable and flexible way for users to try out new concepts and build prototypes with the ATmega328P microcontroller from various combinations of performance, power consumption, and features. The Arduino Uno has 14 digital input/output pins (of which six can be used as PWM outputs), six analog inputs, a 16 MHz ceramic resonator (CSTCE16M0V53-R0), a USB connection, a power jack, an ICSP header, and reset button. Most of the ATmega328P microcontroller pins are brought to the IO pins on the left and right edge of the board, which are then connected to two existing mikroBUS™ sockets. This Click Shield also has several switches that perform functions such as selecting the logic levels of analog signals on mikroBUS™ sockets and selecting logic voltage levels of the mikroBUS™ sockets themselves. Besides, the user is offered the possibility of using any Click board™ with the help of existing bidirectional level-shifting voltage translators, regardless of whether the Click board™ operates at a 3.3V or 5V logic voltage level. Once you connect the Arduino UNO board with our Click Shield for Arduino UNO, you can access hundreds of Click boards™, working with 3.3V or 5V logic voltage levels.

Click Shield for Arduino UNO accessories 1 image

Used MCU Pins

mikroBUS™ mapper

Encode Output B
PC0
AN
ID SEL
PD2
RST
SPI Select / ID COMM
PB2
CS
SPI Clock
PB5
SCK
SPI Data OUT
PB4
MISO
SPI Data IN
PB3
MOSI
Power Supply
3.3V
3.3V
Ground
GND
GND
Encoder Output A
PD6
PWM
Switch Output
PC3
INT
NC
NC
TX
NC
NC
RX
NC
NC
SCL
NC
NC
SDA
Power Supply
5V
5V
Ground
GND
GND
1

Take a closer look

Click board™ Schematic

Rotary B 2 Click Schematic schematic

Step by step

Project assembly

Click Shield for Arduino UNO front image hardware assembly

Start by selecting your development board and Click board™. Begin with the Arduino UNO Rev3 as your development board.

Click Shield for Arduino UNO front image hardware assembly
Arduino UNO Rev3 front image hardware assembly
Charger 27 Click front image hardware assembly
Prog-cut hardware assembly
Charger 27 Click complete accessories setup image hardware assembly
Arduino UNO Rev3 Access MB 1 - upright/background hardware assembly
Necto image step 2 hardware assembly
Necto image step 3 hardware assembly
Necto image step 4 hardware assembly
Necto image step 5 hardware assembly
Necto image step 6 hardware assembly
Arduino UNO MCU Step hardware assembly
Necto No Display image step 8 hardware assembly
Necto image step 9 hardware assembly
Necto image step 10 hardware assembly
Debug Image Necto Step hardware assembly

Track your results in real time

Application Output

1. Application Output - In Debug mode, the 'Application Output' window enables real-time data monitoring, offering direct insight into execution results. Ensure proper data display by configuring the environment correctly using the provided tutorial.

2. UART Terminal - Use the UART Terminal to monitor data transmission via a USB to UART converter, allowing direct communication between the Click board™ and your development system. Configure the baud rate and other serial settings according to your project's requirements to ensure proper functionality. For step-by-step setup instructions, refer to the provided tutorial.

3. Plot Output - The Plot feature offers a powerful way to visualize real-time sensor data, enabling trend analysis, debugging, and comparison of multiple data points. To set it up correctly, follow the provided tutorial, which includes a step-by-step example of using the Plot feature to display Click board™ readings. To use the Plot feature in your code, use the function: plot(*insert_graph_name*, variable_name);. This is a general format, and it is up to the user to replace 'insert_graph_name' with the actual graph name and 'variable_name' with the parameter to be displayed.

Software Support

Library Description

This library contains API for Rotary B 2 Click driver.

Key functions:

  • rotaryb2_set_led_pos - This function turns on the LED for the selected LED position.

  • rotaryb2_set_led_data - This function, using SPI serial interface, writes a desired 16-bit data.

  • rotaryb2_get_state_switch - This function return rotary encoder switch signal, states of the SW(INT).

Open Source

Code example

The complete application code and a ready-to-use project are available through the NECTO Studio Package Manager for direct installation in the NECTO Studio. The application code can also be found on the MIKROE GitHub account.

/*!
 * @file main.c
 * @brief Rotary B 2 Click example
 *
 * # Description
 * This library contains the API for the Rotary B 2 Click driver
 * to control LEDs states and a rotary encoder position readings.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initialization of SPI module and log UART.
 * After the driver init, the app executes a default configuration and turn off all LEDs.
 *
 * ## Application Task
 * This example demonstrates the use of the Rotary B 2 Click board.
 * The demo example shows the functionality of a rotary encoder used to control LEDs.
 *
 * @author Nenad Filipovic
 *
 */

#include "board.h"
#include "log.h"
#include "rotaryb2.h"

#define ROTARYB2_ONE_LED          ROTARYB2_SET_LED_DATA_1
#define ROTARYB2_TWO_LED          ROTARYB2_SET_LED_DATA_1  | ROTARYB2_SET_LED_DATA_9
#define ROTARYB2_FOUR_LED         ROTARYB2_SET_LED_DATA_1  | ROTARYB2_SET_LED_DATA_5  | \
                                  ROTARYB2_SET_LED_DATA_9  | ROTARYB2_SET_LED_DATA_13
#define ROTARYB2_EIGHT_LED        ROTARYB2_SET_LED_DATA_1  | ROTARYB2_SET_LED_DATA_3  | \
                                  ROTARYB2_SET_LED_DATA_5  | ROTARYB2_SET_LED_DATA_7  | \
                                  ROTARYB2_SET_LED_DATA_9  | ROTARYB2_SET_LED_DATA_11 | \
                                  ROTARYB2_SET_LED_DATA_13 | ROTARYB2_SET_LED_DATA_15
#define ROTARYB2_EIGHT_LED_INV    ROTARYB2_SET_LED_DATA_2  | ROTARYB2_SET_LED_DATA_4  | \
                                  ROTARYB2_SET_LED_DATA_6  | ROTARYB2_SET_LED_DATA_8  | \
                                  ROTARYB2_SET_LED_DATA_10 | ROTARYB2_SET_LED_DATA_12 | \
                                  ROTARYB2_SET_LED_DATA_14 | ROTARYB2_SET_LED_DATA_16

static rotaryb2_t rotaryb2;
static log_t logger;

static uint8_t start_rot_status = 0;
static uint8_t led_demo_state = 0;
static uint8_t old_state = 0;
static uint8_t new_state = 1;
static uint8_t old_rot_state = 0;
static uint8_t new_rot_state = 1;
static uint16_t led_data = 1;

/**
 * @brief Rotary B 2 select LED demo data function.
 * @details This function selects one of the four LED demo data
 * based on the current state of the LED demo.
 * @return LED demo data:
 *         @li @c 0x0001 (ROTARYB2_ONE_LED)   - Turn ON LED[1],
 *         @li @c 0x0101 (ROTARYB2_TWO_LED)   - Turn ON LED[1,9],
 *         @li @c 0x0101 (ROTARYB2_FOUR_LED)  - Turn ON LED[1,5,9,13],
 *         @li @c 0x5555 (ROTARYB2_EIGHT_LED) - Turn ON LED[1,3,5,7,9,11,13,15].
 */
static uint16_t rotaryb2_sel_led_demo_data ( uint8_t led_demo_state );

/**
 * @brief Rotary B 2 switch detection function.
 * @details This function is used for the switch state detection.
 * @return Nothing.
 */
static void rotaryb2_switch_detection ( void );

/**
 * @brief Rotary B 2 encoder mechanism function.
 * @details This function is used to control the state of the LEDs
 * by detecting the rotation direction of the rotary encoder.
 * @return Nothing.
 */
static void rotaryb2_encoder_mechanism ( void );

void application_init ( void )
{
    log_cfg_t log_cfg;  /**< Logger config object. */
    rotaryb2_cfg_t rotaryb2_cfg;  /**< Click config object. */

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, " Application Init " );

    // Click initialization.
    rotaryb2_cfg_setup( &rotaryb2_cfg );
    ROTARYB2_MAP_MIKROBUS( rotaryb2_cfg, MIKROBUS_1 );
    if ( SPI_MASTER_ERROR == rotaryb2_init( &rotaryb2, &rotaryb2_cfg ) )
    {
        log_error( &logger, " Communication init." );
        for ( ; ; );
    }

    if ( ROTARYB2_ERROR == rotaryb2_default_cfg ( &rotaryb2 ) )
    {
        log_error( &logger, " Default configuration." );
        for ( ; ; );
    }

    log_info( &logger, " Application Task " );
}

void application_task ( void )
{
    if ( ROTARYB2_OK == rotaryb2_set_led_data( &rotaryb2, led_data ) )
    {
        rotaryb2_switch_detection( );
        rotaryb2_encoder_mechanism( );
    }
}

int main ( void )
{
    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}

static uint16_t rotaryb2_sel_led_demo_data ( uint8_t led_demo_state )
{
    switch ( led_demo_state )
    {
        case 0:
        {
            return ROTARYB2_ONE_LED;
            break;
        }
        case 1:
        {
            return ROTARYB2_TWO_LED;
            break;
        }
        case 2:
        {
            return ROTARYB2_FOUR_LED;
            break;
        }
        case 3:
        {
            return ROTARYB2_EIGHT_LED;
            break;
        }
        default:
        {
            return ROTARYB2_ONE_LED;
            break;
        }
    }
}

static void rotaryb2_switch_detection ( void )
{
    if ( rotaryb2_get_state_switch( &rotaryb2 ) )
    {
        new_state = 1;
        if ( (  1 == new_state ) && ( 0 == old_state ) )
        {
            old_state = 1;
            led_demo_state = ( led_demo_state + 1 ) % 5;
            if ( 4 == led_demo_state )
            {
                for ( uint8_t n_cnt = 0; n_cnt < 10; n_cnt++ )
                {
                    rotaryb2_set_led_data( &rotaryb2, ROTARYB2_EIGHT_LED_INV );
                    Delay_ms( 100 );
                    rotaryb2_set_led_data( &rotaryb2, ROTARYB2_EIGHT_LED );
                    Delay_ms( 100 );
                }

                for ( uint8_t led_p = ROTARYB2_SET_LED_POS_1; led_p <= ROTARYB2_SET_LED_POS_16; led_p++ )
                {
                    rotaryb2_set_led_pos( &rotaryb2, led_p );
                    Delay_ms( 100 );
                }

                led_demo_state = 0;
                led_data = rotaryb2_sel_led_demo_data( led_demo_state );
            }
            else
            {
                led_data = rotaryb2_sel_led_demo_data( led_demo_state );
            }
        }
    }
    else
    {
        old_state = 0;
    }
}

static void rotaryb2_encoder_mechanism ( void )
{
    if ( rotaryb2_get_state_ena( &rotaryb2 ) == rotaryb2_get_state_enb( &rotaryb2 ) )
    {
        old_rot_state = 0;
        start_rot_status = rotaryb2_get_state_ena( &rotaryb2 ) && rotaryb2_get_state_enb( &rotaryb2 );
    }
    else
    {
        new_rot_state = 1;
        if ( new_rot_state != old_rot_state )
        {
            old_rot_state = 1;
            if ( start_rot_status != rotaryb2_get_state_ena( &rotaryb2 ) )
            {
                led_data = ( led_data << 1 ) | ( led_data >> 15 );
            }
            else
            {
                led_data = ( led_data >> 1 ) | ( led_data << 15 );
            }
        }
    }
}

// ------------------------------------------------------------------------ END
