优化引脚利用率，减少板载复杂性，使用 CY8C9540A 和 STM32F103RB

/*!
 * \file
 * \brief Expand7 Click example
 *
 * # Description
 * This example demonstrates the use of the EXPAND 7 Click.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initalizes I2C driver and makes an initial log.
 *
 * ## Application Task
 * This example shows the capabilities of the EXPAND 7 Click by toggling
 * each of the 40 available pins.
 *
 * \author MikroE Team
 *
 */
// ------------------------------------------------------------------- INCLUDES

#include "board.h"
#include "log.h"
#include "expand7.h"

// ------------------------------------------------------------------ VARIABLES

static expand7_t expand7;
static log_t logger;

// ------------------------------------------------------ APPLICATION FUNCTIONS

void application_init ( void )
{
    log_cfg_t log_cfg;
    expand7_cfg_t cfg;

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, "---- Application Init ----" );

    //  Click initialization.
    expand7_cfg_setup( &cfg );
    EXPAND7_MAP_MIKROBUS( cfg, MIKROBUS_1 );
    expand7_init( &expand7, &cfg );
    Delay_ms ( 100 );

    log_printf( &logger, "------------------- \r\n" );
    log_printf( &logger, "   EXPAND 7 Click   \r\n" );
    log_printf( &logger, "------------------- \r\n" );
}

void application_task ( void )
{
    expand7_write_all ( &expand7, 0xFF );
    log_printf( &logger, "All pins set to HIGH logic level!\r\n" );
    log_printf( &logger, "---------------------------------\r\n" );
    Delay_ms ( 1000 );
    Delay_ms ( 1000 );

    for ( uint8_t pin_num = 0; pin_num < 40; pin_num++ )
    {
        expand7_write_pin( &expand7, pin_num, EXPAND7_LOW );
        log_printf( &logger, "Pin %u is set to LOW logic level!\r\n", ( uint16_t ) pin_num );
        Delay_ms ( 300 );
    }
    log_printf( &logger, "---------------------------------\r\n" );
    Delay_ms ( 1000 );
}

int main ( void )
{
    /* Do not remove this line or clock might not be set correctly. */
    #ifdef PREINIT_SUPPORTED
    preinit();
    #endif

    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}

// ------------------------------------------------------------------------ END
