 * \file
 * \brief TempHum13 Click example
 *
 * # Description
 * This demo shows basic TempHum13 Click functionality - temperature
 * and humidity measurement.
 *
 * The demo application is composed of two sections :
 *
 * ## Application Init
 * Initialize device.
 *
 * ## Application Task
 * Measure temperature and humidity values on every 0,5 seconds,
 * and log them to UART Terminal if they are valid.
 *
 *
 * \author MikroE Team
 *
 */
// ------------------------------------------------------------------- INCLUDES

#include "board.h"
#include "log.h"
#include "temphum13.h"

// ------------------------------------------------------------------ VARIABLES

static temphum13_t temphum13;
static log_t logger;

static float temperature;
static float humidity;

// ------------------------------------------------------ APPLICATION FUNCTIONS

void application_init ( void )
{
    log_cfg_t log_cfg;
    temphum13_cfg_t cfg;

    /**
     * Logger initialization.
     * Default baud rate: 115200
     * Default log level: LOG_LEVEL_DEBUG
     * @note If USB_UART_RX and USB_UART_TX
     * are defined as HAL_PIN_NC, you will
     * need to define them manually for log to work.
     * See @b LOG_MAP_USB_UART macro definition for detailed explanation.
     */
    LOG_MAP_USB_UART( log_cfg );
    log_init( &logger, &log_cfg );
    log_info( &logger, "---- Application Init ----" );

    //  Click initialization.

    temphum13_cfg_setup( &cfg );
        Delay_ms ( 500 );
    TEMPHUM13_MAP_MIKROBUS( cfg, MIKROBUS_1 );
        Delay_ms ( 500 );
    temphum13_init( &temphum13, &cfg );
        Delay_ms ( 500 );

    temphum13_default_cfg( &temphum13 );
}

void application_task ( void )
{
    temperature = temphum13_get_temperature( &temphum13 );
    humidity = temphum13_get_humidity( &temphum13 );

    if ( temperature != 65536.0 )
    {
        log_printf( &logger, "\r\n> Temperature : %.2f C", temperature );
    }

    if ( humidity != 65536.0 )
    {
        log_printf( &logger, "\r\n> Humidity    : %.2f%%RH\r\n", humidity );
    }

    Delay_ms ( 500 );
}

int main ( void )
{
    /* Do not remove this line or clock might not be set correctly. */
    #ifdef PREINIT_SUPPORTED
    preinit();
    #endif

    application_init( );

    for ( ; ; )
    {
        application_task( );
    }

    return 0;
}

// ------------------------------------------------------------------------ END
